Supermicro Motherboard H12SSL-CT (bulk pack)
Single AMD EPYC(TM) 7003/7002 Series Processors
(7003 Series Processor drop-in support requires BIOS version 2.0 or newer)
2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
Expansion slots:
5 PCI-E 4.0 x16
2 PCI-E 4.0 x8
M.2 Interface: 2 PCI-E 4.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-key
8 SATA3, Broadcom 3008 SAS3 (12 Gbps) controller for 2 SAS3 ports, 2 M.2
Dual 10GBase-T LAN via Broadcom BCM57416
ASPEED AST2500 BMC graphics
Up to 6 USB 3.0 ports
(4 rear + 2 via header)
7 PWM 4-pin Fans with tachometer status monitoring
Form factor: ATX
Dimensions: 12" x 9.6" (30.5cm x 24.4cm)
Price on request
Immediately available (1-2 business days)
Supermicro Motherboard X12SPA-TF (bulk pack)
3rd Gen Intel® Xeon® Scalable processors,
Intel® Xeon® W-3300 Processor
Single Socket LGA-4189 (Socket P+) supported,
CPU TDP supports Up to 270W TDP
Intel® C621A
Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Marvell AQC113
Single LAN with Realtek RTL8211F PHY (dedicated IPMI)
Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz,
Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 4TB Intel® Optane(TM) Persistent Memory,
DDR4-3200MHz, in 16 DIMM slots
4 PCI-E 4.0 x16,
3 PCI-E 4.0 x8 (in x16 slot)
M.2 Interface: 4 PCI-E 4.0 x4
M.2 Form Factor: 2260/2280/22110
M.2 Key: M-Key
M.2 support to RAID 0,1, 5, 10, VROC key is required for RAID.
Intel® C621A controller for 8 SATA3 (6 Gbps) ports,
RAID 0,1,5,10
1 VGA port,
VGA connector is dedicated for IPMI.
Form Factor: E-ATX
Dimensions: 13" x 12" (33.02cm x 30.48cm)
Price on request
Immediately available (1-2 business days)
Supermicro Motherboard X10DRX (bulk pack)
Dual socket R3 (LGA 2011) supports
Intel Xeon processor E5-2600
v4/ v3 family, QPI up to 9.6GT/s
Intel C612 chipset
Up to 2TB ECC 3DS LRDIMM, up to
DDR4- 2400MHz, 16x DIMM slots
Expansion slots: 10 PCI-E 3.0 x8 and
1 PCI-E 2.0 x4 (in x8) slot
Intel i350 Dual port GbE LAN
10x SATA3 (6Gbps), RAID 0, 1, 5, 10
Integrated IPMI 2.0 and KVM with
Dedicated LAN
5x USB 3.0 ports, 4x USB 2.0 ports
2x SuperDOM ports, TPM header
Form Factor: Proprietary, 15.2 x 13.2 (38.6cm x 33.5cm)
Price on request
Immediately available (1-2 business days)
Supermicro Motherboard X10SRH-CLN4F (bulk pack) -EOL-
Single socket R3 (LGA 2011) supports
Intel Xeon processor E5-2600 v3
and E5-1600 v3 family
Intel C612 chipset
Up to 512GB ECC DDR4 2133MHz
LRDIMM, 8x DIMM slots
1 PCI-E 3.0 x4 (in x8), 1 PCI-E 3.0 x8
(in x16), 2 PCI-E 3.0 x8, 1 PCI-E 2.0
x2 (in x4), 1 PCI-E 2.0 x4 (in x8)
Intel i350-AM4 Quad port GbE LAN
10x SATA3 (6Gbps) via C612
8x SAS3 (12Gbps) via LSI 3008 SW
controller, RAID 0, 1, 10
1x VGA, 2x COM, 1x TPM
4x USB 3.0 ports, 8x USB 2.0 ports
2x SuperDOM with built-in power
Form Factor: ATX 12" x 9.6"
Price on request
No longer available
Supermicro Motherboard X11DDW-NT (retail pack)
2nd Generation Intel Xeon Scalable Processors (Cascade Lake-SP), Intel Xeon Scalable Processors.
Dual Socket P (LGA 3647) supported, CPU TDP support 205W, 2 UPI up to 10.4 GT/s
Intel C622
Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz, Up to 3TB 3DS ECC LRDIMM, DDR4-2933MHz, in 12 DIMM slots,
Up to 2TB Intel Optane DC Persistent Memory in memory mode (Cascade Lake only).
1 PCI-E 3.0 x32 Left Riser Slot,
PCI-E 3.0 x16 Right Riser Slot,
PCI-E 3.0 x16 for Add-On-Module (AOM)
M.2 Interface: PCIe 3.0 x4
M.2 Form Factor: 2242, 2260, 2280, 22110
M.2 Key: M-Key
U.2 Interface: PCIe 3.0 x4,
4 PCI-E 3.0 NVMExpress x4 Internal Port(s)
1 VGA port(s)
Intel C622 controller for 14 SATA3 (6 Gbps) ports, RAID 0,1,5,10
Dual LAN with 10Gbase-T
from C622
Factor: Proprietary WIO, Dimensions: 12.3" x 13.4" (31.24cm x 34.04cm)
Price on request
No longer available
Supermicro Motherboard X12SDV-4C-SPT8F (bulk pack)
System on Chip
Intel Xeon Processor D-2712T, CPU TDP 65W
Up to 256GB Registered ECC RDIMM, DDR4-3200MHz
Up to 512GB LRDIMM LRDIMM, DDR4-3200MHz, in 4 DIMM slots
1 PCI-E 4.0 x16
2 PCI-E 4.0 NVMe x8 SlimSAS Internal Port
1 OCuLink Connector (4 SATA/PCI-E 3.0 x4)
1 M.2 M-Key 2242/2280 (SATA/PCI-E 3.0 x4)
Quad 1G RJ45 with Intel I350-AM4
Dual 25G SFP28 with Intel SoC
Dual 10Gbase-T RJ-45 with Intel Ethernet Controller X550-AT2
SoC controller for 2 SATA3 (6 Gbps) ports RAID 0,1
12V DC or ATX Power Input
Form Factor: Micro-ATX
Dimension: 7.5" x 8.5" (19.05cm x 21.59cm)
Price on request
No longer available
Supermicro Motherboard H11SSW-iN (bulk pack) Board Rev. 2.x Rome ready
Single AMD EPYC 7002-Series (ROME) Processor
2TB Registered ECC DDR4
3200MHz SDRAM in 16 DIMMs
Expansion slots:
1 PCI-E 3.0 x32 Left Riser Slot
1 PCI-E 3.0 x16 Right Riser Slot
M.2 Interface: 2 PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-key
12 NVMe via SlimSAS,
4 NVMe or 16 SATA3 via SlimSAS,
2 M.2,
2 SATA3
2x 1GbE LAN Ports via Broadcom
BCM5720L,
1 Realtek RTL8211E PHY
(dedicated IPMI)
ASPEED AST2500 BMC graphics
Up to 7 USB 3.0 ports
(4 rear + 2 front + 1 Type A)
6 PWM 4-pin Fans with
tachometer status monitoring
Form Factor: Proprietary, Dimensions: 13.4" x 12.29" (34cm x 31.2cm)
Price on request
No longer available
Supermicro Motherboard X12STW-TF (bulk pack), refurbished
Intel Xeon E-2300 Processor,
10th Generation Intel Pentium Processor,
Single Socket LGA-1200 (Socket H5) supported,
CPU TDP supports Up to 95W TDP
Intel C256
Up to 128GB Unbuffered ECC UDIMM, DDR4-3200MHz
1 PCI-E 4.0 x16 Left Riser Slot
1 PCI-E 3.0 x4 (in x8, Right Riser slot)
M.2 Interface: 1 PCI-E 4.0 x4 and 1 PCI-E 3.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key Double Height Connector
Dual LAN with Intel X550 10GBase-T Ethernet Controller
Intel C256 controller for 8 SATA3 (6 Gbps) ports
RAID 0,1,5,10
1 VGA port
4 USB 3.2 Gen1 ports (2 rear + 2 via headers)
1 USB 3.2 Gen2 port (1 Type A)
6 USB 2.0 ports (2 rear + 4 via headers)
Form Factor: Proprietary WIO
Dimensions: 8" x 13" (20.32cm x 33.02cm)
Price on request
No longer available
Supermicro Motherboard X14SAZ-F (retail pack)
Micro-ATX Embedded Motherboard
Intel® Core® Ultra 9/7/5 Series 2 Processors
Supports 12V DC power input
Onboard TPM9672: TCG 2.0, FIPs 140-2 Level 2,
Intel TXT and Microsoft Windows certification
Intel® Core™ Ultra 9/7/5 Series 2 Processor,
CPU TDP supports Up to 125W TDP
Intel® W880
Up to 256GB Unbuffered ECC/non-ECC UDIMM/CUDIMM,
DDR5-5600MHz, in 4 DIMM slots
1 PCIe 5.0 x16 slot, 2 PCIe 4.0 x4 slots, 2 PCIe 4.0 x4 MCIO port M.2 Interface: 1 PCIe 5.0 x4 M.2 Form Factor: 2280/22110 M.2 Key: M-Key
Dual 2.5 Gigabit LAN with Intel® Ethernet i226LM LAN controller [AMT/vPro]
4 Independent Displays (1 VGA port, 2 DP++ ports, 2 HDMI 2.1 port)
Intel® W880 Controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Form Factor: Micro-ATX
Dimension: 9.6" x 9.6" (24.38cm x 24.38cm)
Price on request
No longer available
Supermicro Motherboard X14SAZ-F (bulk pack)
Micro-ATX Embedded Motherboard
Intel® Core® Ultra 9/7/5 Series 2 Processors
Supports 12V DC power input
Onboard TPM9672: TCG 2.0, FIPs 140-2 Level 2,
Intel TXT and Microsoft Windows certification
Intel® Core™ Ultra 9/7/5 Series 2 Processor,
CPU TDP supports Up to 125W TDP
Intel® W880
Up to 256GB Unbuffered ECC/non-ECC UDIMM/CUDIMM,
DDR5-5600MHz, in 4 DIMM slots
1 PCIe 5.0 x16 slot, 2 PCIe 4.0 x4 slots, 2 PCIe 4.0 x4 MCIO port M.2 Interface: 1 PCIe 5.0 x4 M.2 Form Factor: 2280/22110 M.2 Key: M-Key
Dual 2.5 Gigabit LAN with Intel® Ethernet i226LM LAN controller [AMT/vPro]
4 Independent Displays (1 VGA port, 2 DP++ ports, 2 HDMI 2.1 port)
Intel® W880 Controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Form Factor: Micro-ATX
Dimension: 9.6" x 9.6" (24.38cm x 24.38cm)
Price on request
No longer available
Supermicro Motherboard X13SAW-F (retail pack)
Supports 12V DC power input
Onboard TPM2.0
Intel® Core Processors Series 2 & 14th/13th/12th Gen Core i Processor,
Single Socket LGA-1700 supported,
CPU TDP supports Up to 125W TDP
Intel® R680E
Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR5-4400MHz,
in 4 DIMM slots
1 PCIe 5.0 x16 slot, 1 PCIe 4.0 x4 slots, 2 PCIe 4.0 x4 MCIO
1 M.2 M-Key 2280 (PCIe 3.0 x4) 1 M.2 M-Key 2280/22110 (PCIe 4.0 x4)
Dual 2.5 Gigabit LAN with Intel® Ethernet i226 LAN controller
Intel® R680E Controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
2 Independent Display Ports (2 DP1.4)
Form Factor: Proprietary Embedded
Dimensions: 8" x 13" (20.32cm x 33.02cm)
Price on request
No longer available
Supermicro Motherboard X11SWN-L (bulk pack)
Intel 8th Generation Core? i3-8145UE Processor
Dual Channel DDR4 2400MHz SO-DIMM, up to 64GB
Intel UHD Graphics 620 with 4K and 24 EU for Vision Solution
3 display support(DP++, HDMI and 48-bit LVDS)
Small form factor with rich I/O: 2 GbE, 8 USB and 6 COM
Rich expansion: 3 x M.2 (B/E/M key) for NVMe/SATA/Wifi/BT/LTE
12-24V wide range power input with RVP and TVS
Form Factor : 3.5" SBC, Dimensions: 5.7" x 4.0" (14.6cm x 10.16cm)
Price on request
No longer available
Supermicro Motherboard A1SRM-2758F (bulk pack)
Intel Atom processor C2758, SoC,
FCBGA 1283, 20W 8-Core
Up to 64GB DDR3 1600MHz ECC or
non-ECC UDIMM in 4 DIMM sockets
Quad GbE LAN ports
IPMI with dedicated LAN
2x SATA3 and 4x SATA2 ports
1x PCI-E 2.0 x8, 1x PCI-E 2.0 x4
7x USB 2.0 ports
Operating Temperature: 0°C - 60°C
7-Year product life
Form Factor: uATX, Dimensions: 9.6" x 7.5" (24.4cm x 19.05cm)
Price on request
No longer available
Supermicro Motherboard X10DRH-CT (bulk pack)
Dual socket R3 (LGA 2011) supports
Intel Xeon processor E5-2600
v4/ v3 family, QPI up to 9.6GT/s
Intel C612 chipset
Up to 2TB ECC 3DS LRDIMM, up to
DDR4- 2400MHz, 16x DIMM slots
1x PCI-E 3.0 x16, 6x PCI-E 3.0 x8 slots
Intel X540 Dual port 10GBase-T
10x SATA3 (6Gbps) ports w/ Intel
C612 controller, RAID 0, 1, 5, 10
8x SAS3 (12Gbps) ports w/ LSI 3108
controller (2GB cache), RAID 0, 1, 5,
6, 10, 50, 60
Integrated IPMI 2.0 and KVM with
Dedicated LAN
5x USB 3.0 and 4x USB 2.0 ports
Form Factor: E-ATX 12 x 13 (30.5cm x 33.2cm)
Price on request
No longer available
Supermicro Motherboard X12SPW-TF (bulk pack)
3rd Gen Intel® Xeon® Scalable processors,
Single Socket LGA-4189 (Socket P+) supported,
CPU TDP supports Up to 270W TDP
Intel® C621A
Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz,
Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 2TB Intel® Optane(TM) Persistent Memory
200 Series, in 8 DIMM slots
1 PCI-E 4.0 x16 Right Riser Slot,
1 PCI-E 4.0 x32 Left Riser Slot,
4 PCI-E 4.0 NVMe x4 Internal Port(s)
M.2 Interface: PCI-E 3.0 x4 and SATA
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
Dual LAN with 10GBase-T with Intel® X550
Intel® C621A controller for 10 SATA3 (6 Gbps) ports,
RAID 0,1,5,10
I/O: 1 VGA, 2 COM, TPM header
2 SuperDOM with built-in power
Form Factor: Proprietary WIO
Dimensions: 8" x 13" (20.32cm x 33.02cm)
Price on request
No longer available
Supermicro Motherboard X10SDV-6C+-TLN4F (retail pack)
Intel Xeon processor D-1528,
Single socket FCBGA 1667,
6-Core, 12 Threads, 35W
System on Chip
Up to 128GB ECC RDIMM DDR4
2133MHz or 64GB ECC/non-ECC
UDIMM in 4 sockets
1 PCI-E 3.0 x16,
M.2 PCI-E 3.0 x4 (SATA support),
M Key 2242/2280
2 10GbE and 2 GbE LAN ports
6 SATA3 (6Gbps) ports via SoC
2 USB 3.0 ports (rear)
4 USB 2.0 ports (via headers)
1 SuperDOM, 1 COM, TPM
header, GPIO and SMbus headers
12V DC input and ATX Power Source
Form Factor: Mini-ITX, Dimensions: 6.7" x 6.7" (17cm x 17cm)
Price on request
No longer available
Supermicro Motherboard X11SBA-LN4F (bulk pack)
Intel Pentium Processor N3700,
Single socket FCBGA 1170, 6W
System-on-Chip
Up to 8GB 1600MHz DDR3 Non-ECC SO-DIMM in 2 sockets
1x PCI-E 2.0 x1 (in x8),
1x Mini-PCIe (mSATA support)
Quad GbE LAN with Intel i210-AT
1x HDMI, 1x DP, Intel HD Graphics,
VGA port for BMC
2x USB 3.0 ports (2 rear), 7x USB 2.0 (2 rear, 4 via headers, 1 Type A)
I/O: 1x SATA DOM, 2x COM, TPM 1.2 header, ALC 888S HD Audio
IPMI 2.0 with dedicated Port and KVM
Supports 12V DC power input
Form Factor: Mini-ITX, Dimensions: 6.7" x 6.7" (17.02cm x 17.02cm)
Price on request
No longer available
Supermicro Motherboard X11SBA-LN4F (bulk pack) -refurbished-
Intel Pentium Processor N3700,
Single socket FCBGA 1170, 6W
System-on-Chip
Up to 8GB 1600MHz DDR3 Non-ECC SO-DIMM in 2 sockets
1x PCI-E 2.0 x1 (in x8),
1x Mini-PCIe (mSATA support)
Quad GbE LAN with Intel i210-AT
1x HDMI, 1x DP, Intel HD Graphics,
VGA port for BMC
2x USB 3.0 ports (2 rear), 7x USB 2.0 (2 rear, 4 via headers, 1 Type A)
I/O: 1x SATA DOM, 2x COM, TPM 1.2 header, ALC 888S HD Audio
IPMI 2.0 with dedicated Port and KVM
Supports 12V DC power input
Form Factor: Mini-ITX, Dimensions: 6.7" x 6.7" (17.02cm x 17.02cm)
Price on request
No longer available
Supermicro Motherboard X10DRH-I (bulk pack)
Dual socket R3 (LGA 2011) supports
Intel Xeon processor E5-2600
v4/ v3 family, QPI up to 9.6GT/s
Intel C612 chipset
Up to 2TB ECC 3DS LRDIMM, up to
DDR4- 2400MHz, 16x DIMM slots
1x PCI-E 3.0 x16, 6x PCI-E 3.0 x8 slots
Intel i350 Dual port GbE LAN
10x SATA3 (6Gbps) ports w/ Intel
C612 controller, RAID 0, 1, 5, 10
Integrated IPMI 2.0 and KVM withDedicated LAN
5x USB 3.0 and 4x USB 2.0 ports
Form Factor: E-ATX 12" x 13", 1U and up Server
Price on request
No longer available
Supermicro Motherboard X13SAV-PS (retail pack)
12th Gen Intel® Core(TM) processors
Intel® Celeron® processors, SoC,
Single Socket LGA-1700 supported,
CPU TDP supports Up to 65W TDP
Up to 64GB Unbuffered non-ECC SODIMM,
DDR5-4800MHz, in 2 SODIMM slots
1 PCIe 4.0 x4 slot
1 M.2 M-Key 2280 (PCIe 4.0 x4)
1 M.2 E-Key 2230 (PCIe 3.0 x1/USB2.0)
1 M.2 B-Key 3052 (PCIe 3.0 x2/USB3.0/USB2.0)
Dual 2.5 Gigabit LAN with Intel® Ethernet i225LM
LAN controller [AMT/vPro]
4 Independent Displays (1 DP ports, 1 HDMI port,
2 TYPE C support DP/USB3.0)
Supports 12V DC power input
Onboard TPM2.0
Form Factor: Mini-ITX
Dimensions: 6.7" x 6.7" (17.02cm x 17.02cm)
Price on request
No longer available
Supermicro Motherboard A4SAP-L (retail pack)
Intel® processor N97 (12W, 4C)
1 M.2 B-Key 2242/3042, 1 M.2 E-Key 2230
1 HDMI, 1 48-bit LVDS, Intel® HD Graphic 2 independent displays
Supports 12V DC power input
2 USB 3.2 ports (rear), 2 USB 2.0 ports (via headers), 2 COM ports (via headers)
Form Factor: Pico-ITX
Dimensions: 4" x 2.83" (10.16cm x 7.19cm)
Price on request
No longer available
Supermicro Motherboard X11SCL-LN4F (bulk pack)
8th/9th Generation Intel Core?i3/Pentium/Celeron Processor, Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor., Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP
Intel C242
Up to 128GB Unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
1 PCI-E 3.0 x16
M.2 Interface: 1 PCI-E 3.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key
Double Height Connector
Quad LAN with Intel Ethernet Controller I210-AT
Intel C242 controller for 6 SATA3 (6 Gbps) ports, RAID 0,1,5,10
5x USB 3.0 ports, 4x USB 2.0 ports
1 VGA, 1 COM, 1 TPM
2 SuperDOM with built-in power
Form Factor: Micro-ATX
Dimensions: 9.6" x 9.6" (24.38cm x 24.38cm)
Price on request
No longer available
Supermicro Motherboard X11SDV-8C-TP8F (retail pack)
Intel Xeon Processor D-2146NT, CPU TDP support Up to 80W TDP
System on Chip
Up to 256GB Registered ECC RDIMM, DDR4-2133MHz, Up to 512GB LRDIMM LRDIMM, DDR4-2133MHz, in 4 DIMM slots
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x16
Mini-PCI-E with mSATA support
1 M.2 M-Key SATA/PCI-E 3.0 x4, 2280
1 M.2 B-Key SATA/PCI-E 3.0 x2, 3042
U.2 Interface: 2 PCI-E 3.0 x4,
2 PCI-E 3.0 NVMe x4 Internal Port(s)
1 VGA D-Sub Connector port
SoC controller for 12 SATA3 (6 Gbps) ports, RAID 0,1,5,10
Quad LAN with Intel Ethernet Controller I350-AM4
Dual LAN with 10G SFP+ LAN via SoC
Dual LAN with 10Gbase-T
Intel Quick Assist Technology
Supports 12V DC power input
Form Factor: Flex-ATX
Dimensions: 9" x 7.25" (22.86cm x 18.42cm)
Price on request
No longer available
Supermicro Motherboard X10SDV-2C-TP4F (retail pack)
Intel Pentium processor D1508,
Single socket FCBGA 1667,
2-Core, 4 Threads, 25W
Up to 128GB ECC RDIMM DDR4
1866MHz or 64GB ECC/non-ECC
UDIMM in 4 sockets
2 PCI-E 3.0 x8,
Mini PCI-E (mSATA support),
M.2 PCI-E 3.0 x4 (SATA support),
M Key 2242/2280/22110
2 10G SFP+ and 2 GbE LAN
4 SATA3 (6Gbps) ports via SoC
2 USB 3.0 ports (rear), 5 USB
2.0 ports (4 via headers, 1 Type A)
2 SuperDOM, 1 COM, TPM 2.0
header, GPIO and SMbus headers
12V DC input and ATX Power Source
Form Factor: Flex ATX, Dimensions: 9.0" x 7.25", (22.86cm x 18.42cm)
Price on request
No longer available
Motherboards - this is what you should ask yourself
Which processor should be mounted?
The motherboard provides the socket for the processor (CPU). It is soldered there permanently and cannot be replaced later: Both Intel and AMD now offer a large number of processors. In our store, we have preselected the options that are relevant for you. So you don't lose time with unmanageable lists. Whether AMD EPYC, AMD RYZEN, Intel Core and/or Intel Xeon 2nd or 3rd Generation Scalable Processors - with us you can easily get your motherboard from Supermicro or Gigabyte with the right processor for you.
